    HY680X Mini Skid Steer Loader
    Picture Viewer
    Request Price
  • HY680X Mini Skid Steer Loader

    The skid steer loader is also called a multi-purpose engineering vehicle. It is a wheeled special chassis equipment that uses the difference in the linear velocity of the wheels on both sides to realize the steering of the vehicle. It has the characteristics of flexible steering, compact body and can be equipped with multi-function tools.


    No operating license required
    Easy to operate
    Factory direct sale
    Support customization
    With CE, Epa/Euro V
    With various accessories
    features and benefits
HY680X Mini Skid Steer Loader

The skid steer loader is also called a multi-purpose engineering vehicle. It is a wheeled special chassis equipment that uses the difference in the linear velocity of the wheels on both sides to realize the steering of the vehicle. It has the characteristics of flexible steering, compact body and can be equipped with multi-function tools.
It is mainly suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residential buildings, etc.

  • Engine Power 18.4kw
  • Dimensions 2600*1250*1257mm
  • Rated Loading Weight 320kg
  • 2
  • 1(共四张,这一张可做主图)
  • 3
  • CUSTOMIZATION SUPPORTED

    Logo/color/engine/etc


    We can provide you with exclusive customization services, and will produce the products you want according to your requirements, including but not limited to logo customization, color customization.

  • EPA/EURO V ENGINE


    Standard with Standard with Perkins 403J-11 18.4kw or Kubota D1105 18.2kw,diesel engine.

  • EASY OPERATING,SIMPLE MAINTENANCE


    Compact dimensions , Wide range of uses。

    It is an ideal choice for working in places where the site is small, the ground is undulating, and the job content changes frequently.It is suitable for infrastructure construction, industrial application, dock loading and unloading, urban streets, residences, barns, livestock houses, airport runways, etc., and can also be used as auxiliary equipment for large-scale construction machinery.
About Accessories
parmeters

Specifications

Rated Loading Weight 450kg
Bucket Capacity 0.2m³
Maximum Lifting Weight 1200kg
Work Speed 0-6.5 Km/h
Rated Pressure 21Mpa
Lifting Time 4.3s
Maximum Unloading Height 2940mm
Bucket Lowering Time 3.3s
Dimensions (mm) 2880*1235*1510mm
Gradeability 30
Machine Operating Weight 1300kg
Engine Model Kubota D1105
Engine Info Diesel ,three-cylinders
Rated Power 18.2kw/3000rpm
Start Method Electric
Hydraulic Box 25l
Motor Oil Box 5.1l
Fuel Box 35l
